| Brand Name: | Realkey |
| Model Number: | Realkey-CBS |
| MOQ: | 1 |
| Price: | USD 10000/Piece |
| Payment Terms: | L/C,T/T,D/P |
| Supply Ability: | The customized products need to be based on the specified plan. |
| Attribute | Value |
|---|---|
| Cart Pitch | 600mm |
| Sorting Accuracy | 99.99% |
| Operating Noise | ≤72dB（A） |
| Sorted Goods Weight | 0.03kg≤W≤30kg |
| Operating Speed | 2.0m/s |
| Sorting Efficiency | 22000 pieces per hour |
Realkey's Cross Belt Sorter is a next-generation sorting system engineered to handle medium-sized packages with exceptional speed and accuracy. Featuring a modular, space-efficient design, this system is ideal for high-volume distribution centers and logistics operations that require automated sorting of up to 22,000 items per hour.
Built with precision and scalability in mind, the Cross Belt Sorter incorporates motorized carts, cross-directional belts, smart recognition systems, high-speed communication interfaces, and a dynamic control framework. The system's design allows carts to travel along a continuous track. At their assigned destinations, the control system activates the belts, transferring items swiftly and accurately to the appropriate chute or bin.
| Equipment Name | Circular Cross Belt Sorter(CBS - 600C) | Linear Cross Belt Sorter |
|---|---|---|
| Model | CBS - 600C | CBS - 500L | CBS - 300L |
| Sorted Items | Various parcels, cartons, clothing, books, etc. | |
| Cart Pitch | 600mm | 500mm | 300mm |
| Sorting Accuracy | 99.99% | |
| Sorting Efficiency | 22000 pieces per hour | 6000 pieces per hour | 8000 pieces per hour |
| Feeding Method | Manual loading / Automatic loading from feeding station | |
| Sorted Goods Size | MAX: 700*600*500mm; MIN: 150*150*8mm | |
| Scanning Method | Top scan / Three-phase five-sided scan / Six-sided scan | |
| Sorted Goods Weight | 0.03kg ≤ W ≤ 20kg | 0.03kg ≤ W ≤ 20kg | 0.1kg ≤ W ≤ 30kg |
| Operating Speed | 2.0m/s | 1.5m/s |
| Operating Noise | ≤72dB (A) | |
Realkey Cross Belt Sorters are widely used in industries that demand multi-directional, space-efficient, and labor-saving solutions:
Common applications include:
Smarter Automation for Modern Logistics
From global e-commerce hubs to regional delivery centers, the Realkey Cross Belt Sorter is designed to reduce labor intensity, maximize throughput, and adapt to diverse operational needs. For businesses managing increasing parcel volumes and complex distribution demands, this system delivers future-ready performance--today.
