| Brand Name: | Realkey |
| Model Number: | RKCONV-RC |
| MOQ: | 1 unit |
| Price: | USD 10000/Piece |
| Payment Terms: | L/C,T/T,D/P |
| Attribute | Value |
|---|---|
| Custom Order | Accept |
| OEM/ODM | Accept |
| Factory | Direct Factory With Own Exporting Platform |
| Feature | Applicable to various industrial fields |
| Content | Technical Parameters |
|---|---|
| Model | RKCONV-RC-38/50/60/76/89 |
| Length | Customizable |
| Effective Width | 400/600/800/1000/1200(mm) |
| Roller Diameter | 38/50/60/76/89(mm) |
| Roller Center Distance | 60/90/120/150(mm) |
| Roller Material | Carbon Steel (Galvanized)/Stainless Steel |
| Transmission Mode | Chain/Multi-Wedge Belt/O-Belt |
| Conveying Type | Flat/Turning/Centering/Side/Accumulation/Merging |
| Drive Type | Non-powered/Reduction Motor/Friction Belt/Electric Roller |
| Operating Speed | 0.1~2.0(m/s) |
| Maximum Load | 50(kg/㎡) |
| Operating Temperature | -20~40(℃) |
| Operating Voltage | No power source/Three-phase five-wire 380V/Single-phase 220V |
| Additional Equipment | Configurable with side guards, photoelectric switches, foot switches, stoppers, etc. |
