| Brand Name: | Realkey |
| Model Number: | RKLOAD-TBC |
| MOQ: | 1 unit |
| Price: | USD 10000/Piece |
| Payment Terms: | L/C,D/P,T/T |
| Custom Order | Accept |
| OEM/ODM | Accept |
| Factory | Direct Factory With Own Exporting Platform |
| Feature | Flexibly adjustable in length and angle, this design suits various transportation scenarios. |
| Model | Sections | Fixed Section Length(mm) | Extended Section Length(mm) | Total Length(mm) | Characteristic |
|---|---|---|---|---|---|
| TBC2-5+3 | Two | 5000 | 3000 | 8000 |
Belt Width (mm): 400/600/800/900/1000 Belt Material: PVC/PVK/Composite Belt Operating Speed: 0.2~0.6 (m/s) Maximum Load: 60 (kg/m²) Ambient Temperature: -20~40 (℃) Ambient Voltage: Three-phase five-wire 380V Hydraulic Lift: Optional OEM/ODM: Customized design and manufacturing according to customer requirements are supported. |
| TBC2-7+5 | 7000 | 5000 | 12000 | ||
| TBC3-5+6 | Three | 5000 | 6000 | 11000 | |
| TBC3-6+8 | 6000 | 8000 | 14000 | ||
| TBC3-7+9.5 | 7000 | 9500 | 16500 | ||
| TBC4-4+6 | Four | 4000 | 6000 | 10000 | |
| TBC4-5+9 | 5000 | 9000 | 14000 | ||
| TBC4-6+12 | 6000 | 12000 | 18000 | ||
| TBC4-7+14 | 7000 | 14000 | 21000 | ||
| TBC5-6+14 | Five | 6000 | 14000 | 20000 | |
| TBC5-7+17 | 7000 | 17000 | 24000 |
