| Brand Name: | Realkey |
| Model Number: | RKCONV-MC |
| MOQ: | 1 unit |
| Price: | USD 10000/Piece |
| Payment Terms: | L/C,D/P,T/T |
| Custom Order | Accept |
| OEM/ODM | Accept |
| Factory | Direct Factory With Own Exporting Platform |
| Feature | Modular, Hygienic, Quiet, Versatile, Energy-Efficient Conveyor |
The RKCONV Modular Belt Conveyor (RKCONV-MC) utilizes a modular plastic belt as its core conveying medium. Its operation is akin to standard belt conveyors, employing a drive system to ensure continuous movement of the modular belt for efficient and precise transport of various items.
This conveyor is lightweight, easy to maintain, and integrates smoothly into existing systems, making it ideal for industries such as food processing, pharmaceuticals, electronics assembly, and mail sorting. It supports heavier loads, making it suitable for lateral transport of larger or heavier items.
The curved modular conveyor can be configured to turn at angles including 30°, 45°, 60°, 90°, and 180°, or any specified angle. Customizable turning radii enable creation of complex conveying systems when combined with other conveyor lines.
| Specification | Technical Parameters |
|---|---|
| Model Number | RKCONV-MC-L/M/H |
| Equipment Length | 3~20 meters |
| Effective Width | 400/600/800/1000/1200/1400mm |
| Belt Material | PU/POM |
| Conveyor Type | Flat/Climbing/Turning |
| Drive Type | Geared Motor |
| Operating Speed | 0.2~1.5 (m/s) |
| Maximum Load | 120 kg/square meter |
| Ambient Temperature | -20~40 (℃) |
| Ambient Voltage | Three-phase Five-wire 380V/Single-phase 220V |
| Equipment Accessories | Can be configured with accessories such as protective panels, bottom mesh, photoelectric switches, foot switches, etc. |
