| Brand Name: | Realkey |
| Model Number: | RKCONV-BC |
| MOQ: | 1 unit |
| Price: | USD 10000/Piece |
| Payment Terms: | L/C,T/T,D/P |
| Attribute | Value |
|---|---|
| Custom Order | Accept |
| OEM/ODM | Accept |
| Factory | Direct Factory With Own Exporting Platform |
| Feature | Strong transport capacity, simple structure and easy maintenance, low noise |
The Realkey Belt Conveyor (RKCONV-BC) is a high-performance material handling system integrating conveyor belt, drive unit, structural framework, and advanced control mechanism. Engineered for stable operation with high efficiency, low noise, and reduced energy consumption.
| Parameter | Specification |
|---|---|
| Model | RKCONV-BC-204/206/209/211 |
| Length | 1.2~20(m) |
| Effective Width | 400/600/800/1000/1200/1400(mm) |
| Belt Material | PVC/PVK/PU/Composite Belt |
| Conveying Types | Flat/Inclined/Curved/Merging |
| Drive Types | Gear Motor/Electric Drum, Center Drive/End Drive |
| Operating Speed | 0.2~2.3(m/s) |
| Maximum Load | 80(kg/㎡) |
| Ambient Temperature | -20~40(℃) |
| Voltage | Three-phase Five-wire 380V/Single-phase 220V |
